1. Introduction

FiberView-400A uses the OTDR principle to measure the fiber backscatter signal and combine the unique analysis algorithm to directly give the fiber link event type, location and light power. The test is smart, accurate, simple and fast, and requires no complicated training. Especially suitable for field engineers.

2. Features

>FiberView-400A is a hand-held design instrument that is compact, lightweight and easy to carry.

>Event information and simple curves are displayed on the LCD and have a data storage function.

>The test data can be uploaded to the PC via the USB interface, and the loss curve of the fiber link is graphically displayed for post processing, archiving and printing.

>2.5mm universal connector for a wide range of connector types.

>FiberView-400A also adds optical power measurement. The power meter can measure 5 standard wavelengths, and the measurement range and stability meet the requirements of practical applications, which is a useful supplement to the OTDR function.

3. Applications

>Telecommunications construction and maintenance

>Integrated wiring system

>Other fiber engineering

>CATV project construction and maintenance

>Optical device production and research
